JUKI LS-341N Cylinder Bed Unison Feed Sewing Machine

Description

JUKI LS-341N Cylinder Bed Unison Feed Sewing Machine

Heavy-duty single-needle cylinder-bed lockstitch machine designed for sewing medium- to heavy-weight materials where strong material feeding and consistent stitch quality are required.

The JUKI LS-341N uses a unison-feed system, combining the feed dog, needle and alternating presser-foot movement for reliable feeding of difficult materials. Its cylinder-bed design is well suited to curved, tubular and three-dimensional workpieces. The machine is equipped with a vertical-axis 1.6-fold-capacity hook, maximum stitch length of 6mm and adjustable alternating vertical movement of approximately 2.3–6mm.

Key Features

• Single-needle lockstitch machine
• Cylinder-bed construction
• Unison-feed / compound-feed mechanism
• Vertical-axis 1.6-fold-capacity hook
• Strong feeding performance for medium- to heavy-weight materials
• Maximum stitch length: 6mm
• Alternating vertical movement: 2.3–6mm
• Presser-foot lift: 8.5mm by hand / 15mm by knee
• Safety mechanism provided as standard
• Suitable for curved and three-dimensional sewing applications

Specifications

• Brand: JUKI
• Model: LS-341N
• Machine type: 1-needle cylinder-bed lockstitch
• Feed system: Unison feed
• Maximum sewing speed: 2,000 rpm
• Maximum stitch length: 6mm
• Needle bar stroke: 33.4mm
• Presser-foot lift: 8.5mm hand / 15mm knee
• Alternating vertical movement: 2.3–6mm
• Hook: Vertical-axis, 1.6-fold-capacity
• Needle: DP×17, #14–#24
• Thread range: approximately #40–#8
• Cylinder-bed diameter: 72mm
• Distance from needle to machine arm: 250mm
• Machine-head weight: approximately 36kg
• Lubrication: Manual/oiler system
• Specifications may vary depending on exact subclass and configuration.

Suitable For:
Leather Goods • Bags • Handbags • Luggage • Footwear • Upholstery • Automotive Interiors • Canvas Products • Belts • Saddlery • Heavy Fabrics • Technical Textiles • Curved Components • Tubular Components • Three-Dimensional Sewing
