Fucen FC-341 Heavy-Duty Cylinder-Bed Compound Feed Lockstitch Sewing Machine

Description

Fucen FC-341 Heavy-Duty Cylinder-Bed Compound Feed Lockstitch Sewing Machine

Heavy-duty single-needle cylinder-bed walking foot lockstitch machine engineered for structural assembly, edge binding, and heavy decorative topstitching on bulky, tubular, and three-dimensional goods. The Fucen FC-341 utilizes an advanced synchronized unison compound feed mechanism (bottom feed, needle feed, and alternating walking presser feet) to drive dense leather, heavy canvas, and multi-layered technical textiles without ply slippage, bunching, or stitch-length variation. Built on a large-diameter cylinder arm with extended working clearance, it provides complete freedom of motion around large bag bottoms, curved gussets, luggage shells, and tubular shapes.

Constructed on a rigid, vibration-absorbing cast-iron chassis, the machine is equipped with a large vertical-axis rotary hook that holds substantially more bobbin thread, minimizing bobbin changes when utilizing thick synthetic bonded nylon or polyester threads. An elevated needle-bar stroke paired with extra-high presser foot lift allows operators to climb over thick overlapping cross-seams and bulky assemblies smoothly. Equipped with a simple-dial stitch regulator and a responsive manual reverse lever for instant backtacking, the FC-341 delivers superior seam strength and reliable performance across demanding leathercraft and heavy bag manufacturing lines.

Key Features

• Heavy-duty cylinder-bed walking-foot lockstitch sewing machine

• Unison compound feed system (needle feed, drop feed, alternating walking feet) for slip-free material transport

• Extended cylindrical arm designed for easy maneuvering of three-dimensional, curved, and tubular products

• Large vertical-axis hook configuration accommodating thick industrial threads and large-capacity bobbins

• Extra-high presser foot lift clearance for effortless loading and handling of dense, multi-layer workpieces

• High needle-penetration force engineered to pierce dense leathers, heavy webbing, and synthetic polymers

• Convenient manual reverse feed lever for rapid seam reinforcement and backtacking

• Easily adapted with synchronous binder attachments for heavy tape binding and edge finishing

• Heavy-duty cast construction engineered to maintain mechanical alignment under demanding cycle conditions

Specifications

• Brand: Fucen

• Model: FC-341

• Class: Heavy Duty / Cylinder-Bed Series

• Machine Type: Cylinder-Bed Compound Feed Lockstitch Machine

• Stitch Type: 301 Lockstitch

• Number of Needles: 1

• Feed System: Unison Compound Feed (Walking Foot + Needle Feed + Drop Feed)

• Bed Type: Cylinder Bed (approx. 72 mm diameter)

• Maximum Stitch Length: Up to 9 mm

• Presser Foot Lift: Up to 10 mm (by hand) / 16 mm (by knee lifter)

• Needle Bar Stroke: 36–38 mm

• Needle System: DPx17 (135×17) / 134-35

• Needle Size: #18–#24 (Nm 110–180)

• Hook Type: Vertical-Axis Large Capacity Rotary Hook

• Maximum Sewing Speed: Up to 2,000–2,200 stitches/min

Suitable For: Heavy Leather Handbags • Backpacks & Rucksacks • Travel Luggage & Suitcases • Golf Bags & Sports Equipment • Footwear & Work Boots • Leather Belts & Straps • Heavy Canvas Gear • Curved Upholstery Panels • Tactical Gear & Holsters • Structural Edge-Binding Operations
