Kingsew 1341 Cylinder Bed Walking Foot Sewing Machine

Description

Kingsew 1341 Cylinder Bed Walking Foot Sewing Machine

Heavy-duty single-needle cylinder bed lockstitch machine designed for sewing medium- to heavy-weight materials, tubular products and three-dimensional components. The Kingsew 1341 Cylinder Bed uses a compound-feed system combining bottom feed, needle feed and alternating walking-foot top feed to ensure smooth and even material movement.

The synchronized walking-foot mechanism helps prevent material shifting when sewing multiple layers of leather, canvas, vinyl and other difficult materials. Its narrow cylinder-bed design provides excellent access for curved seams, tubular articles and hard-to-reach areas, making it particularly suitable for bags, luggage, footwear, upholstery and leather goods.

The machine is equipped with a large rotary hook for improved bobbin capacity and is built with heavy-duty industrial components for reliable continuous production. The 1341-style cylinder arm is especially effective for sewing shaped and three-dimensional products where a conventional flat-bed machine may be difficult to use.

Key Features

• Single-needle cylinder bed lockstitch machine
• Compound-feed system with bottom feed, needle feed and walking foot
• Alternating walking foot provides smooth and even feeding
• Excellent for multiple layers and medium- to heavy-weight materials
• Narrow cylinder bed for tubular and curved components
• Large vertical-axis rotary hook with increased bobbin capacity
• Long stitch length for heavy-duty sewing applications
• High presser-foot lift for thick materials
• Reverse sewing mechanism for reinforcement stitching
• Adjustable alternating presser-foot movement
• Durable heavy-duty industrial construction
• Suitable for continuous production environments

Specifications

• Brand: Kingsew
• Class: 1341
• Machine Type: Cylinder Bed Walking Foot Sewing Machine
• Stitch Type: 301 Lockstitch
• Number of Needles: 1
• Number of Threads: 2
• Feed System: Bottom Feed + Needle Feed + Alternating Walking Foot
• Maximum Stitch Length: Up to 9mm
• Maximum Sewing Speed: Up to 2,000–2,500 stitches/min
• Presser Foot Lift: Up to 16mm
• Cylinder Bed Diameter: Approximately 72mm
• Needle System: DP × 17 / 135 × 17
• Hook: Large Vertical-Axis Rotary Hook
• Lubrication: Automatic / Centralized lubrication system
• Reverse Feed: Manual reverse stitching
• Applications: Medium- to heavy-duty materials and tubular products

Suitable For: Leather Goods • Handbags • Luggage • Backpacks • Footwear • Upholstery • Automotive Interiors • Car Mats • Canvas Products • Filters and Industrial Bags • Tubular Products • Curved and Three-Dimensional Components
